1. ZT310-VX battery bottom cover(dark grey matte)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:Due to the battery bottom cover changes,ZT310-V1&VX models need to purchase “1224200-040000 ZT310 Electric parts box lower cover” if need to replace the old battery bottom cover;if for ZT310-V colloid battery models,you need to purchase “1224200-040000 ZT310 Electric parts box lower cover”and “1224200-110000 ZT310－V rear inner plate”.M6×12 bolts must be used at the rear,otherwise the bolt protrudes too long and may damage the battery.
|
|
|
|
2. ZT310 Electric parts box lower cover
|
|
|
|
|
|
|
|
3. ZT310-VX battery bracket
|
|
|
|
|
|
|
|
4. ZT310 gel battery strap
|
|
|
|
|
|
|
|
5. ZT310 colloid battery (6-FM-10/10Ah)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: The outline is about 196 × 114 × 61mm; it is recommended to use “1184300-026000 ZT350 lead-acid battery charger” to charge,or use the lithium battery charger that comes with the lithium battery.The lithium battery version of the ZT310-R / X / T series can purchase modification kit for colloidal batteries in modified pieces.The voltage should be checked regularly, and it should be charged in time if it is below 12volts.When the motorcycles is not used for a long time, the battery should be removed for storage and recharged once a month.Pay attention to distinguish between positive and negative poles during installation.
|
|
|
|
6. GB16674 M6×16 Hexagon flange bolts (9.8 grade/environmental color Zinc)
|
|
|
|
|
|
|
|
7. Non-standard bolt M6×12 (304 stainless steel)
|
|
|
|
|
|
|
|
8. Flanged bushing φ6.2×φ8.4×3.5＋φ14×1.5(5 pcs/after-sale)
|
|
|
|
|
|
|
|
9. flanging bushing buffer rubber (φ8.5×φ14×1)(5 pcs/after-sale)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
11. ZT310-R relay of side support
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: Model G8HN-1C4T-RJ.
|
|
|
|
12. HJ125-6 Battery rubber gasket(5 pcs/after-sale)
|
|
|
|
|
|
|
|
