1. ZT310-R electric device box (colloid battery)
|
|
|
|
|
|
|
|
2. Plywood M6×11×15(color Zinc)
|
|
|
|
|
|
|
|
3. HJ125-6 Battery rubber gasket
|
|
|
|
|
|
|
|
4. ZT310PKE external single antenna
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Note: If the original motorcycle is a new state single-antenna PKE controller, this material can be purchased separately. Click or download the image on the left to see a larger picture. If you need the velcro can purchase "1226400-188000 Velcro (External Single Antenna)" for after-sale.
|
|
|
|
5. ZT310 PKE new version (band version )
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: The old "ZT310 PKE Controller (Single Antenna)" for ZT250-R National IV and 310 series models can purchase this assmbly directly and the antenna uses the single antenna of the original car.If the original car is a "ZT310 PKE controller with dual antennas", it must be used with the purchase of "1184200-053000 ZT310PKE external single antenna".The battery type of the sensor key is Camelion CR1225.
|
|
|
|
6. Battery for key (CR1225)
|
|
|
|
|
|
|
|
7. ZT310 Induction Key (Bracelet Edition)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: If you can not purchase this sensor key , please consult your salesman for more details.
|
|
|
|
8. Bracelet key battery cover
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:Only battery cover ,no other accessories. Only for small battery version of induction key.
|
|
|
|
9. Bracelet key battery cover (enlarge battery)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:Only battery cover ,no other accessories. Only for big battery version of induction key.
|
|
|
|
10. ZT310 PKE Assembly (enlarge battery induction key)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: The battery type of the sensor key is CR2032.
|
|
|
|
11. Button battery (Camelion CR2032)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:Just for the enlarge battery version PKE Induction Key .
|
|
|
|
12. ZT310 Induction Key (Bracelet Edition-enlarge battery)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:If you need to purchase the sensor key , please consult your salesman for details.
|
|
|
|
13. Non-standard bolt M6×16 (304 stainless steel)
|
|
|
|
|
|
|
|
14. 6.3×12×1.6 copper gasket
|
|
|
|
|
|
|
|
15. ZT310 induction key rubber ring
|
|
|
|
|
|
|
|
16. ZT310-R1 On-board Tools
|
|
|
|
|
|
|
|
17. MSE6.0 controller-ZT180MN (Euro 5)
|
|
|
|
|
|
|
|
18. MSE6.0 controller -ZT180MN
|
|
|
|
|
|
|
|
19. ZT310-R relay of side support
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: Model G8HN-1C4T-RJ.
|
|
|
|
20. ZT310 Electric parts box lower cover
|
|
|
|
|
|
|
|
21. ZT310PKE External antenna mount
|
|
|
|
|
|
|
|
22. ZT250-S fuel-injection relay
|
|
|
|
|
|
|
Quantity
|
|
|
3
|
|
Remarks: Model KH-1A4T-R.
|
|
|
|
23. ZT310 colloid battery (6-FM-10/10Ah)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: The outline is about 196 × 114 × 61mm; it is recommended to use “1184300-026000 ZT350 lead-acid battery charger” to charge,or use the lithium battery charger that comes with the lithium battery.The lithium battery version of the ZT310-R / X / T series can purchase modification kit for colloidal batteries in modified pieces.The voltage should be checked regularly, and it should be charged in time if it is below 12volts.When the motorcycles is not used for a long time, the battery should be removed for storage and recharged once a month.Pay attention to distinguish between positive and negative poles during installation.
|
|
|
|
|
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:Please use original parts!Otherwise may cause damage to the ECU!Any loss caused by the using of non-original parts does not beling to the scope of guarantees.
|
|
|
|
25. ZT310 gel battery strap
|
|
|
|
|
|
|
|
26. ZT310 lead acid battery charger
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: Use with colloidal batteries; do not charge lithium batteries.This charger has been discontinued,you can buy"1184300-026000 ZT350 colloidal battery charger"instead.
|
|
|
|
27. ZT310 Lead Acid Battery Charger (European Standard)
|
|
|
|
|
|
|
|
28. ZT368 Battery Charger (European)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:This 368 charger does not come with a charging adapter and can be purchased on request. If you have purchased or given away the 350 charger at your own expense, you can use the adapter cable that comes with the original charger, and you do not need to purchase an adapter cable; If the original car does not provide a charger, it needs to be used with the purchase adapter cable to charge the battery. The old charger that is not included with the car is not accepted for return and replacement if the quality of the charger itself is not accepted. Models with a complimentary charger are only a charger, not a charging adapter. Models of 250CC and below need to purchase this charger by themselves, models with PKE can not buy adapter cables, models without PKE need to purchase adapter cables, factory is not standard.
|
|
|
|
29. ZT368 Battery Charger
|
|
|
|
|
|
|
|
30. Charger adapter cable
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: If it is a model with PKE, the alligator clip can be used to connect the charged battery, and the DC5.5 male plug connected by the adapter cable is powered on by PKE or the charging port holder, which is convenient for occasions where it is not convenient to connect to the 220V power supply. Models without PKE need to purchase an adapter cable to directly charge the battery with the charger. Models above 250CC (excluding 250CC) that have a complimentary charger with the vehicle are only free chargers and do not give charging adapters, and need to purchase them by themselves. Pay attention to distinguish between positive and negative plates, avoid reverse connection, red connected to the positive pole of the battery, black connected to the negative pole.
|
|
|
|
31. ZT310-R battery holder (gel battery)
|
|
|
|
|
|
|
|
32. Non-standard bolt M6×12 (304 stainless steel)
|
|
|
|
|
|
|
|
33. Flanging bushing φ6.2×φ8.4×3.5＋φ14×1.5
|
|
|
|
|
|
|
|
34. Buffer rubber of flanging bushing (φ8.5×φ14×1)
|
|
|
|
|
|
|
|
35. GB6177.1M6 (environmental color)
|
|
|
|
|
|
|
|
36. Battery anode protection glue
|
|
|
|
|
|
|
|
37. ZT310 battery clip to DC mother charging adapter
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: Non-complete vehicle standard. It is convenient to take the battery home when charging, and it needs to be used together with "1184200-038044 ZT310 lithium battery charger".
|
|
|
|
38. ZT310 univsersal fuse (10A small)
|
|
|
|
|
|
|
Quantity
|
|
|
8
|
|
Remarks: Small 10A.
|
|
|
|
39. ZT310 univsersal fuse (15A small)
|
|
|
|
|
|
|
Quantity
|
|
|
6
|
|
Remarks: Small 15A.
|
|
|
|
40. ZT310 univsersal fuse (25A small)
|
|
|
|
|
|
|
Quantity
|
|
|
3
|
|
Remarks: Small 25A.
|
|
|
|
41. ZT310-R Colloidal battery case cover
|
|
|
|
|
|
|
|
42. Velcro (external single antenna )
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks:The external PKE antenna of individual models is pasted on the cover, and it is recommended to purchase this part at the same time if you need to replace the cover.
|
|
|
|
