1. ZT310T-M rear wheel output shaft dust cover
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Note: The ZT310T-M produced in the early stage can be retrofitted by itself. It serves to protect the threads of the rear wheel output shaft and for decorative purposes. This part is universal for scooter series models. This model has been discontinued and can be replaced by purchasing the "A3-01 Rear Wheel Output Shaft Dust Cover".
|
|
|
|
2. A3-01 rear wheel output shaft dust cover(after-sale)
|
|
|
|
|
|
|
|
3. GB6187.1M16×1.5 (Dacromet)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Remarks: 21# sleeve.
|
|
|
|
4. ZT368T-E Rear Swingarm Axle Sleeve (II/Φ20×Φ28×10)
|
|
|
|
|
|
|
|
5. ZT368T-E Rear Wheel Axle Sleeve (II/Φ20×Φ28×18/Shoulder OD Φ48)
|
|
|
|
|
|
|
|
6. Non-standard plum blossom groove shoulder bolt M8 × 25-φ10 × 6 (grade 10.9/thread glue/zinc nickel black)
|
|
|
|
|
|
|
Quantity
|
|
|
5
|
|
Note: Use a T45 perforated box-end wrench.
|
|
|
|
7. ZT368T-M rear brake disc (240×4.5) components
|
|
|
|
|
|
|
|
8. ZT368T-D rear aluminum wheel (MT3.75×14/dark gold)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Note: This rim cannot be selected for the 350 series scooters. Due to the difficulty in ensuring color consistency across batches with the painting process, there may be slight color differences between different batches of products, which do not affect normal use.This rim is used in conjunction with the rear axle sleeve of Φ20×Φ28×18.
|
|
|
|
9. ZT368T-M Rear Aluminum Wheel Aftermarket Component (MT3.75×14 - Dark Gold - Ⅱ)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Note: This rim can only be used in conjunction with the rear axle sleeve of Φ20.1×Φ48×Φ28×29, and the after-sales components include the rear axle sleeve. Since the painting process makes it difficult to ensure consistent color for each batch, there may be slight color differences in products from different batches, which do not affect normal use.
|
|
|
|
10. ZT350 Tire Pressure Sensor N (M8 Elbow/120°)(after-sale)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Note: Pay attention to the orientation during installation. Tire sealant is prohibited as it may clog the air hole of the tire pressure monitoring sensor, leading to inflation difficulty or TPMS failure. For 310M models, please check that there is a light sensor in the upper right corner of the instrument cluster before purchasing this product. The old aluminum alloy hex nut indicated by the arrow requires a size 12 wrench; it will be switched to a stainless steel lock hex nut requiring a size 13 wrench around September 24,2026. Tightening torque: 7N. m.
|
|
|
|
11. 140/70-14 CM-SC13 68S TL E4 IMARK
|
|
|
|
|
|
|
|
12. Non-standard bolt M6×16 (304 stainless steel)
|
|
|
|
|
|
|
|
13. Wheel speed sensor(A)
|
|
|
|
|
|
|
|
14. Wheel speed sensor clamp
|
|
|
|
|
|
|
|
15. Wheel rim balancing block (15g-Norton rubber-XT)
|
|
|
|
|
|
|
|
16. Wheel rim balancing block (10g-Norton rubber-XT)
|
|
|
|
|
|
|
|
17. ZT350 independent valve (M8 elbow/120°)(after-sale)
|
|
|
|
|
|
|
Quantity
|
|
|
1
|
|
Note: Pay attention to the orientation during installation. Tire sealant should not be used, as it may clog the air hole of the tire pressure monitoring sensor, leading to difficulty in inflation or failure of the tire pressure monitoring system. The old aluminum alloy hex nut indicated by the arrow requires a No. 12 wrench, and it will be switched to a stainless steel lock hex nut requiring a No. 13 wrench around September 24,2026. Tightening torque: 7N. m.
|
|
|
|
