175X

| Multi-angle Exhibition|Technical Data|Highlights

Multi-angle Exhibition

175X Titanium Metallic (Chinese IV)

➤

175 X Special black (Chinese IV)

➤

Technical Data

Whole vehicle

length (mm)	1975
Width (mm)	750
Height (mm)	1245
Wheel base (mm)	1375
Loading capacity (kg)	101
Gross mass (kg)	110
Minimum ground clearance (mm)	135
Gasoline tank volume (L)	11
Seat height (mm)	770

Power system

The body	Aluminum alloy
Cylinder number	Single cylinder
Camshaft system	Single overhead camshaft(SOHC)
Bore X Stoke (mm)	60.5×58.7
Cooling system	Water cooling
Fuel	95 and above
Compression ratio	11.8 : 1
Displacement(ml)	168.7
Fuel supply method	Intelligent electrical fuel injection
Electrical fuel injection system	BOSCH
Ignition system	Electronic ignition
Idling speed (r/min)	1700 ± 100
Maximum power (kW/rpm)	14.5/8700
Maximum torque (N.m/rpm)	16.5/6500
Transmission type	CVT Automatic Transmission
Economical consumption of fuel (L/km)	2.4/100

Suspension system

Frame system	Aluminum alloy frame
Tire structure	Semi-slick tires
Front rim size	MT:2.75×14
Rear rim size	MT:3.5×13
Front tire specification	110/70-14
Rear tire specification	130/70-13
Front brake specification	Disc brake
Rear brake specification	Disc brake
Headlamp/tail light/steering lamp	LED
Brake system	Dual-Channel ABS System

Unstoppable

Witness a New Era

The 169cc engine features a four-valve design and a 11.8:1 compression ratio, paired with
an efficient liquid-cooling system. It delivers class-leading output of 14.5 kW and 16.5 N·m
while maintaining low fuel consumption. A linerless pure aluminum cylinder, lightweight
forged piston, and DLC-coated piston rings ensure excellent heat dissipation, strong power
output, and superior fuel efficiency. Piston cooling, dedicated lubrication, and dual oil filtration
effectively minimize wear, resulting in a more stable and durable engine.

100000 11.8:1

169cc

High Compression Ratio

1000 14.5

Maximum Power

1000 16.5

N·m

Maximum Torque

One-Piece Cast Aluminum Frame

The world's first high-strength, lightweight one-piece cast aluminum frame in the 175cc class, tipping the scales at no more than 8.5 kg.
The total curb weight of just 110 kg is significantly lighter than comparable models in its class.
This lightweight construction translates into outstanding handling — the nimble chassis delivers an intuitive, connected riding experience where power is always on tap.
Even riders with a smaller build will find daily maneuvering effortless.

Lightweight Platform

The combination of efficient power and a lightweight
platform delivers exceptional performance, firmly
establishing the 150X as a leader in its class.

Spacious and Versatile Storage

Generous storage throughout the motorcycle accommodates a wide range of everyday needs.

Large-Capacity Under-Seat Storage

Fits two standard full-face helmets simultaneously.

Storage compartments

The left front compartment fits a phone for charging; the left and right front compartments can each hold a 550 ml bottle of drinking water.

Convenient Front Hook

Gives riders an additional option for carrying small items (recommended maximum load: 1 kg) for quick and easy access.

Confident Ergonomics, Enjoyable Riding

"The carefully engineered riding triangle accommodates riders from 5'0"" to 6'1"", making it easy to find a comfortable riding position.
Optional sport footpegs are available for shorter riders, providing added confidence and effortless control."

11L Large-Capacity Fuel Tank

Combined with its efficient powertrain and lightweight chassis, the 150X delivers an impressive fuel range of up to 450 km on a full tank, eliminating the hassle of frequent fill-ups.

Purpose-Built Tires

Working in concert with the high-rigidity aluminum frame, the tires confidently handle varying speeds and road conditions — wet or dry — delivering consistent grip for a stable, secure ride at all times.

Meticulously Tuned Front and Rear Suspension

Effectively filters out harsh impacts for a superior ride quality and all-round comfort. The rear suspension features a twin-tube design with 5-step adjustable preload, offering flexible adaptation to varying load requirements. The lightweight spring design contributes to light, agile handling.

Precisely Tuned Braking System

Delivers a linear feel and strong stopping power, with a 100–0 km/h braking distance that leads the class.

Technology-Enabled, Seamlessly Connected

5-Inch TFT Full-Color HD Instrument Display

All key vehicle information at a glance. Choose from three UI themes. Supports smartphone connectivity for navigation projection,
screen mirroring, and OTA remote updates. A full suite of practical functions is available, including mobile phone Bluetooth connection, call display and answering,
tire pressure monitoring, automatic brightness adjustment, real-time vehicle data monitoring, and vehicle diagnostics.

3.0 Keyless Control System

The Generation 3.0 keyless control system supports CAN communication for real-time interaction with the ECU, instrument panel, and other components.
Equipped with 4G, GPS, and Bluetooth capabilities, the mini proximity key awakens the vehicle's full power for every ride.

ZONTES SMART

ZONTES SMART offers multiple vehicle management functions, including remote vehicle control, vehicle data access, vehicle authorization for other users, ride tracking, and remote upgrades.

Breaking Boundaries, Lighting the Way Ahead

LED headlight

Four high-output LED projector modules deliver a wide beam pattern, ensuring clear visibility in all weather and road conditions.

"X" LED Position Light

The distinctive "X"-shaped LED position light gives the model a strong visual identity.

Combination LED Taillight

Integrates seamlessly with the motorcycle's sharp bodywork, offering a wide viewing angle with highly conspicuous brake and turn signal illumination.

Multi-Layer Protection for Total Peace of Mind

Raised windscreen

Deflects airflow and reduces noise, relieving wind pressure on the chest for easier long-distance touring.

One-piece aluminum alloy rear grab handle

Combining strength with a quality feel, it allows a top case to be fitted directly, carrying both a passenger and luggage.

The direction has put on the protective cover.

Enhanced sense of hierarchy.

Start-stop function

Responsive and reliable, it makes every wait at a standstill quieter, more energy-efficient and more environmentally friendly.

Pre-Drilled Camera Mounting Points

Factory-installed mounting points at both the front and rear of the motorcycle allow for straightforward dash cam installation.

Total Control at Your Fingertips

The new Bosch fuel injection system makes every ride safer and more reliable.

Monitors the operational status of the front and rear wheels in real time, ensuring a more stable and comfortable ride over complex road conditions by preventing side-slips and providing greater safety for the rider.
