Multi-angle Exhibition
175V Special black (Chinese IV)
➤
175V Starry Gray (Chinese IV)
➤
Technical Data
Whole vehicle
length (mm)1985
Width (mm)750
Height (mm)1245
Wheel base (mm)1375
Loading capacity (kg)101
Gross mass (kg)110
Minimum ground clearance (mm)135
Gasoline tank volume (L)11
Seat height (mm)770
Power system
The bodyAluminum alloy
Cylinder numberSingle cylinder
Camshaft systemSingle overhead camshaft(SOHC)
Bore X Stoke (mm)60.5×58.7
Cooling systemWater cooling
Fuel95 and above
Compression ratio11.8 : 1
Displacement(ml)168.7
Fuel supply methodIntelligent electrical fuel injection
Electrical fuel injection systemBOSCH
Ignition systemElectronic ignition
Idling speed (r/min)1700 ± 100
Maximum power (kW/rpm)14.5/8700
Maximum torque (N.m/rpm)16.5/6500
Transmission typeCVT Automatic Transmission
Economical consumption of fuel (L/km)2.4/100
Suspension system
Frame systemAluminum alloy frame
Tire structureSemi-slick tires
Front rim sizeMT:2.75×14
Rear rim sizeMT:3.5×13
Front tire specification110/70-14
Rear tire specification130/70-13
Front brake specificationDisc brake
Rear brake specificationDisc brake
Headlamp/tail light/steering lampLED
Brake systemDual-Channel ABS System









Unstoppable
Witness a New Era
The 169cc engine features a four-valve design and a 11.8:1 compression ratio, paired with
an efficient liquid-cooling system. It delivers class-leading output of 14.5 kW and 16.5 N·m
while maintaining low fuel consumption. A linerless pure aluminum cylinder, lightweight
forged piston, and DLC-coated piston rings ensure excellent heat dissipation, strong power
output, and superior fuel efficiency. Piston cooling, dedicated lubrication, and dual oil filtration
effectively minimize wear, resulting in a more stable and durable engine.
100000 11.8:1
169cc
High Compression Ratio
1000 14.5
kW
Maximum Power
1000 16.5
N·m
Maximum Torque
One-Piece Cast Aluminum Frame
The world's first high-strength, lightweight one-piece cast aluminum frame in the 175cc class, tipping the scales at no more than 8.5 kg.
The total curb weight of just 110 kg is significantly lighter than comparable models in its class.
This lightweight construction translates into outstanding handling — the nimble chassis delivers an intuitive,
connected riding experience where power is always on tap. Even riders with a smaller build will find daily maneuvering effortless.


Lightweight Platform
The combination of efficient power and a lightweight
platform delivers exceptional performance, firmly
establishing the 150X as a leader in its class.
Spacious and Versatile Storage
Generous storage throughout the motorcycle accommodates a wide range of everyday needs.
Large-Capacity Under-Seat Storage

Large-Capacity Under-Seat Storage

Fits two standard full-face helmets simultaneously.

左前置物箱

Left front compartment

The left front compartment fits a phone for charging.

右前置物箱

Right front compartment

The right front compartment fits a 550 ml bottle of drinking water.

车头实用挂钩

Convenient Front Hook

Gives riders an additional option for carrying small items (recommended maximum load: 1 kg) for quick and easy access.

Confident Ergonomics, Enjoyable Riding
The carefully engineered riding triangle accommodates riders from 5'0"" to 6'1"", making it easy to find a comfortable riding position.
Optional sport footpegs are available for shorter riders, providing added confidence and effortless control.
油箱
轮胎
减震

11L Large-Capacity Fuel Tank

Combined with its efficient powertrain and lightweight chassis, the 150X delivers an impressive fuel range of up to 450 km on a full tank, eliminating the hassle of frequent fill-ups.

Purpose-Built Tires

Working in concert with the high-rigidity aluminum frame, the tires confidently handle varying speeds and road conditions — wet or dry — delivering consistent grip for a stable, secure ride at all times.

Meticulously Tuned Front and Rear Suspension

Effectively filters out harsh impacts for a superior ride quality and all-round comfort. The rear suspension features a twin-tube design with 5-step adjustable preload, offering flexible adaptation to varying load requirements. The lightweight spring design contributes to light, agile handling.
Precisely Tuned Braking System
Delivers a linear feel and strong stopping power, with a 100–0 km/h braking distance that leads the class.
<%--
--%>
图片加载中...
Technology-Enabled, Seamlessly Connected
5-Inch TFT Full-Color HD Instrument Display
All key vehicle information at a glance. Choose from three UI themes. Supports smartphone connectivity for navigation projection,
screen mirroring, and OTA remote updates. A full suite of practical functions is available, including mobile phone Bluetooth connection, call display and answering,
tire pressure monitoring, automatic brightness adjustment, real-time vehicle data monitoring, and vehicle diagnostics.
3.0 Keyless Control System
The Generation 3.0 keyless control system supports CAN communication for real-time interaction with the ECU, instrument panel, and other components.
Equipped with 4G, GPS, and Bluetooth capabilities for vehicle management via the ZONTES SMART App. The mini proximity key awakens the vehicle's full power for every ride.
ZONTES SMART
ZONTES SMART offers multiple vehicle management functions, including remote vehicle control, vehicle data access, vehicle authorization for other users, ride tracking, and remote upgrades.
Breaking Boundaries, Lighting the Way Ahead
Lightning-bolt position lights
An aggressive, combat-ready front end paired with sharp lightning-bolt position lights, their edges cutting through the play of light and shadow. Every arrival carries a natural aura of speed and power.
Four-matrix projector LED headlight
Independent light sources provide wide, even coverage of the road ahead, with clear night vision and a heightened sense of safety in corners and on challenging roads. Professional-grade lighting comes straight from the factory, with no aftermarket modification needed.
Three-in-one integrated taillight
Clear, even position lights and bright turn signals and brake lights make the bike more conspicuous on the road. The inverted-V taillight echoes the V-shaped front end. Its sharp styling catches the eye at once and instantly lifts the bike's looks.
Multi-Layer Protection for Total Peace of Mind
clone-last
加高风挡
舒适座垫
整车外观
clone-first

Raised windscreen

Deflects airflow and reduces noise, relieving wind pressure on the chest for easier long-distance touring.

One-piece aluminum alloy rear grab handle

Combining strength with a quality feel, it allows a top case to be fitted directly, carrying both a passenger and luggage.

Standard Parking Function

Provides enhanced safety for temporary stops on inclines.

Pre-Drilled Camera Mounting Points
Factory-installed mounting points at both the front and rear of the motorcycle allow for straightforward dash cam installation.
Total Control at Your Fingertips
The new Bosch fuel injection system makes every ride safer and more reliable.
Monitors the operational status of the front and rear wheels in real time, ensuring a more stable and comfortable ride over complex road conditions by preventing side-slips and providing greater safety for the rider.
