150V

| Multi-angle Exhibition|Technical Data|Highlights|Instructions

Multi-angle Exhibition

150V哑光棕（国Ⅳ）

➤

150V磨砂黑（国Ⅳ）

➤

ZT150T-V Matte Bluish-Purple (National IV)

➤

Technical Data

Whole vehicle

length (mm)	1985
Width (mm)	750
Height (mm)	1115
Wheel base (mm)	1375
Loading capacity (kg)	99
Gross mass (kg)	108
Minimum ground clearance (mm)	135
Gasoline tank volume (L)	11
Seat height (mm)	770

Power system

The body	Aluminum alloy
Cylinder number	Single cylinder
Camshaft system	Single overhead camshaft(SOHC)
Bore X Stoke (mm)	58 x 56.6
Cooling system	Water cooling
Fuel	95 and above
Compression ratio	12.5:1
Displacement(ml)	149.5
Fuel supply method	Intelligent electrical fuel injection
Electrical fuel injection system	BOSCH
Ignition system	Electronic ignition
Idling speed (r/min)	1700 ± 100
Maximum power (kW/rpm)	13.2 / 8700
Maximum torque (N.m/rpm)	15.5/6500
Transmission type	自动无级变速
Economical consumption of fuel (L/km)	2.1 /100

Suspension system

Frame system	铝合金车架
Tire structure	Semi-slick tires
Front rim size	MT:2.75×14
Rear rim size	MT:3.5×13
Front tire specification	110/70-14
Rear tire specification	130/70-13
Front brake specification	Disc brake
Rear brake specification	Disc brake
Headlamp/tail light/steering lamp	LED
Brake system	Dual-Channel ABS System

经过浮标，查看更多亮点

车型亮点

Unstoppable

Witness a New Era

The 150cc engine features a four-valve design and a 12.5:1 compression ratio,
paired with an efficient liquid-cooling system. It delivers class-leading output of
13.2 kW and 15.5 N·m while maintaining low fuel consumption. A linerless pure
aluminum cylinder, lightweight forged piston, and DLC-coated piston rings ensure
excellent heat dissipation, strong power output, and superior fuel efficiency.
Piston cooling, dedicated lubrication, and dual oil filtration effectively minimize wear,
resulting in a more stable and durable engine.

100000 12.5:1

150cc

High compression ratio

1000 13.2

Maximum power

1000 15.5

N·m

Maximum torsion

One-Piece Cast Aluminum Frame

The world's first high-strength, lightweight one-piece cast aluminum frame in the 150cc class, tipping the scales at no more than 8.5 kg. The total curb weight of just 108 kg is significantly lighter than comparable models in its class. This lightweight construction translates into outstanding handling — the nimble chassis delivers an intuitive, connected riding experience where power is always on tap. Even riders with a smaller build will find daily maneuvering effortless.

Lightweight Platform

The combination of efficient power and a lightweight platform
delivers exceptional performance, firmly establishing
the 150X as a leader in its class.

Spacious and Versatile Storage

Generous storage throughout the motorcycle accommodates a wide range of everyday needs.

Large-Capacity Under-Seat Storage

Large-Capacity Under-Seat Storage,Fits two standard full-face helmets simultaneously.

左前置物箱

左前置物箱可放入手机充电。

右前置物箱

右前置物箱可放入一瓶550ml饮用水。

Convenient Front Hook

Gives riders an additional option for carrying small items (recommended maximum load: 1 kg) for quick and easy access.

Confident Ergonomics, Enjoyable Riding

The carefully engineered riding triangle accommodates riders from 5'0"" to 6'1"", making it easy to find a comfortable riding position.
Optional sport footpegs are available for shorter riders, providing added confidence and effortless control.

Combined with its efficient powertrain and lightweight chassis, the 150X delivers an impressive fuel range of up to 500 km on a full tank, eliminating the hassle of frequent fill-ups.

Precisely Tuned Braking System

Delivers a linear feel and strong stopping power, with a 100–0 km/h braking distance that leads the class.

<%--

--%>

图片加载中...

Technology-Enabled, Seamlessly Connected

5-Inch TFT Full-Color HD Instrument Display

All key vehicle information at a glance. Choose from three UI themes. Supports smartphone connectivity for navigation projection, screen mirroring, and OTA remote updates.
A full suite of practical functions is available, including mobile phone Bluetooth connection, call display and answering, tire pressure monitoring,
automatic brightness adjustment, real-time vehicle data monitoring, and vehicle diagnostics.

3.0 Keyless Control System

The Generation 3.0 keyless control system supports CAN communication for real-time interaction with the ECU, instrument panel, and other components.

Equipped with 4G, GPS, and Bluetooth capabilities, the mini proximity key, energizing every ride before you even set off.

ZONTES SMART

ZONTES SMART offers multiple vehicle management functions, including remote vehicle control, vehicle data access, vehicle authorization for other users, ride tracking, and remote upgrades.
