Receiving address：
*
ZT250-S oil/oil filter assembly
单价总客 编码数量
   Return



1. ZONTES Engine oil (SN5W-40/1L)
Code：3070100-012100
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
78

2. ZT173YMM refined filter seal component(carton packaging)
Code：4134100-002000
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
46
Remarks:Included refiner,ZT173YMM oil refiner seal and 64.7×2.65 O-ring.
3. 64.7×2.65 Acrylate rubber o-rings
Code：1051453-004000
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
5
Remarks: It is recommended to remove the fine filter cover and replace with a new O-ring to prevent leakage.
4. M12×1.5×15 ablassschraube (9.8 grade/environmental color Zinc)
Code：1251100-066093
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
5
Remark: It is recommended to replace the combination seal 12×φ20×2 at the same time of replacing the oil. ZT310/350 &250-S/R series knight car the standard torque is 24±4N.m;KD/ZT125/150/155-U/U1/G1/Z2/GK is 25±3N.m;ZT125/310/350/368 series scooters 25N.m.
5. Combined sealing gasket 12×φ20×2
Code：1244100-033000
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
4
Remarks: It is recommended to replace with the new parts after disassembly to prevent leakage.
6. ZT173YMM fine filter oil seal
Code：1051453-008000
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
5
Remarks: Be careful not to leak the seal ring.
7.
Code：1251111-038000
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
4

8.
Code：1251300-207000
Local Inventory Unit Price (￥) Equipment Quantity Quantity Sum (￥)   Choose   Buy
in stock
4
