Exhibición multidimensional
ZT150T-X DARK GREEN, (SAMPLE)
➤
ZT150T－Ｘ Matte black（Chinese Ⅳ）
➤
ZT150T-X Matte brown (Chinese IV)
➤
Dato técnico
Vehículo completo
length (mm)1975
Width (mm)750
Height (mm)1115
Wheel base (mm)1375
Loading capacity (kg)99
Gross mass (kg)108
Minimum ground clearance (mm)130
Gasoline tank volume (L)11
Seat height (mm)770
Sistema de energía
The bodyAleación de aluminio
Cylinder numberCilindro singular
Camshaft systemUn solo árbol de levas en cabeza(SOHC)
Bore X Stoke (mm)58 x 56.6
Cooling systemEnfriamiento por agua
Fuel95 y superior
Compression ratio12.5:1
Displacement(ml)149.5
Fuel supply methodInyección de combustible automática
Electrical fuel injection systemBOSCH
Throttle configurationETC
Ignition systemCDI
Idling speed (r/min)1700 ± 100
Maximum power (kW/rpm)13.2 / 8700
Maximum torque (N.m/rpm)15.5/6500
Transmission type自动无级变速
Economical consumption of fuel (L/km)2.1 /100
Sistema de suspensión
Frame system铝合金车架
Tire structureNeumático semi termofusible
Front rim sizeMT:2.75×14
Rear rim sizeMT:3.5×13
Front tire specification110/70-14
Rear tire specification130/70-13
Front brake specificationfreno de disco
Rear brake specificationfreno de disco
Headlamp/tail light/steering lampLED
Brake systemSystème ABS Double Canal
