Multi-angle Exhibition
703RR亮银（国Ⅳ/ETC）
➤
703RR亮银（国Ⅳ/BRM/ETC）
➤
703RR拉法红（国Ⅳ/BRM/ETC）
➤
703RR亮黑（国Ⅳ/BRM/ETC）
➤
703RR拉法红（国Ⅳ/ETC）
➤
703RR亮黑（国Ⅳ/ETC）
➤
Technical Data
Whole vehicle
length (mm)2065
Width (mm)745
Height (mm)1145
Wheel base (mm)1450
Loading capacity (kg)179
Gross mass (kg)195
Minimum ground clearance (mm)145
Gasoline tank volume (L)16
Seat height (mm)795
Power system
The bodyAluminum alloy
Cylinder numberThree-cylinder Engine
Camshaft systemDouble-top camshaft(DOHC)
Bore X Stoke (mm)70 x 60.6
Cooling systemWater cooling
Fuel95 and above
Compression ratio13:1
Displacement(ml)699
Fuel supply methodIntelligent electrical fuel injection
Electrical fuel injection systemMagneti Marelli
Ignition systemElectronic ignition
Transmission systemChain drive
Idling speed (r/min)1350±100
Maximum power (kW/rpm)75 / 11200
Maximum torque (N.m/rpm)74.4 / 8500
GearInternational gears
ClutchWet multi-disk type
Economical consumption of fuel (L/km)5 /100
Suspension system
Frame systemAluminum Alloy Twin Spar Frame
Tire structureRadial Semi-Slick Tires
Front rim sizeMT:3.5×17
Rear rim sizeMT:5.5×17
Front tire specification120/70 ZR17
Rear tire specification180/55 ZR17
Front brake specificationDisc brake
Rear brake specificationDisc brake
Headlamp/tail light/steering lampLED
Brake systemDual channel ABS









Performance Beast
Unconventional and Distinctive
The 699cc three-cylinder, high-revving, liquid-cooled engine has a compression
ratio of up to 13.0:1 and a bore-to-stroke ratio of 1.2:1, delivering a steady output of
over 102 hp, 0–100 km/h in just 3.07 seconds and a top speed above 250 km/h.
Its exceptional performance and high-pitched, powerful exhaust note keep the 703RR
full of fighting spirit at all times, built for track adventures.
100000 13:1
699cc
High Compression Ratio
1000 102
Maximum Horsepower
1000 74.5
N·m
Maximum Torque
Aluminum Alloy Twin-Spar Frame
ZONTES's independently developed and manufactured aluminum alloy twin-spar frame features an integrally-formed main and subframe. The main frame weighs 12 kg and can withstand 20,000 N of force (rated for 2 tons) without failure; the subframe weighs 2.5 kg and can withstand 15,000 N (rated for 1.5 tons). This lightweight, high-strength frame ensures stability and responsive handling at high speeds.
Beyond New Frontiers, Evolved Anew and Sharper Than Ever
6.75-Inch TFT Full-Color HD Instrument Display
Powered by a high-performance quad-core processor, it achieves instantaneous boot-up, an operational response latency of less than 10ms, and flawless performance in extreme temperatures
ranging from -30°C to 85°C. Choose from four UI themes. Supports smartphone connectivity for navigation projection, screen mirroring, and OTA remote updates.
A full suite of practical functions is available, call display and answering, tire pressure monitoring, automatic brightness adjustment, real-time vehicle data monitoring, and vehicle diagnostics.
Standard 6-Axis IMU
By monitoring and analyzing real-time vehicle dynamics — including lean angle, acceleration, and attitude — the system enables Cornering ABS and Cornering TCS, seamlessly integrating riding enjoyment with active safety.
Bi-Directional Quickshifter
A+C Dual-Port Fast-Charge USB
Five Riding Modes
Through different combinations of system parameters, seamlessly switch among five riding modes — Road, Sport, Rain, Off-road, and Rider — to suit any riding scenario.
hollow aluminum alloy swingarm
One-piece construction, masterfully blending art with casting technology for low weight and high strength.
Front ram-air intake
Uses the strong air pressure at high speed to greatly improve intake efficiency and boost power output further.
Front daytime running light
The sci-fi-styled front daytime running light shines as brilliantly as a diamond.
Breathing light
Its refined design seems to bring the motorcycle to life.
Taillight
A highly stylized taillight set into the open-framed rear end, in harmony with the bike's overall styling.
The integrated winglets blend into the bodywork and generate strong downforce at high speed.
Forged Multi-Link Rear Suspension
Equipped with a forged multi-link rear suspension, a rarity in its class, it not only greatly enhances high-speed stability
but also effectively absorbs road imperfections, improving riding comfort.
Marzocchi adjustable front/rear shock absorbers
Marzocchi adjustable front and rear shock absorbers. The front shock features adjustable preload, rebound damping, and compression damping, while the rear shock has adjustable preload and rebound damping,allowing for custom tuning to meet the demands of various road conditions.
J.JUAN direct-push master cylinder
J.JUAN direct-push master cylinder
J.JUAN opposed four-piston radial-mount calipers
J.JUAN opposed four-piston radial-mount calipers
RK/DID 525 high-quality oil-sealed chain
RK/DID 525 high-quality oil-sealed chain
Lightweight aluminum alloy rim
The wide rims feature an ultra-light hollow interior construction that preserves strength and toughness while reducing overall weight and sharpening acceleration response.
3.0 Keyless Control System
The Generation 3.0 keyless control system supports CAN communication for real-time interaction with the ECU, instrument panel, and other components. Equipped with 4G, GPS, and Bluetooth capabilities, the mini proximity key awakens the vehicle's full power for every ride.
ZONTES SMART
The ZONTES SMART App puts complete control at your fingertips, accompanying you every mile of the journey.
Even Stronger, Fearless on Every Journey
16L Galvanized Gasoline Tank with Baking Paint
Eliminate the clogging of intake filter pulp and the leakage of gasoline tank due to rust.
Electronic Fuel Tank Lock
Intelligent anti-theft protection and convenient operation eliminate the hassle of using a key. The newly designed aluminum alloy housing has a modern, high-tech feel.
6AH Lithium Battery
Smaller size, lighter weight, superior low-temperature discharge performance, and a longer service life.
heated grips
The vehicle comes standard with heated grips, and handguards are included as a complimentary accessory, providing thoughtful care for winter riding.
Water/Oil Dual Cooling System
Based on the twin-spar frame architecture, this new product is an innovative design featuring a single, centrally-mounted curved water-cooled radiator with reconfigured key components such as cooling pipes, fins, and a fan. The oil cooler utilizes external air cooling, reducing oil resistance for better heat dissipation. Ride at high speeds without worrying about soaring temperatures, giving the rider a superior experience on the road.
Underslung Muffler
The distinctively styled underslung muffler lowers the motorcycle's center of gravity.
Advanced Electronics for Confident Exploration
The stable and reliable TCS system can monitor the operating status of the front and rear wheels of the vehicle and thereby ensure the vehicle stability and avoid sideslip under complex road conditions, providing a better safety guarantee for drivers
