Multi-angle Exhibition
150V哑光棕（国Ⅳ）
➤
150V磨砂黑（国Ⅳ）
➤
ZT150T-V Matte Bluish-Purple (National IV)
➤
Technical Data
Whole vehicle
length (mm)1985
Width (mm)750
Height (mm)1115
Wheel base (mm)1375
Loading capacity (kg)99
Gross mass (kg)108
Minimum ground clearance (mm)135
Gasoline tank volume (L)11
Seat height (mm)770
Power system
The bodyAluminum alloy
Cylinder numberSingle cylinder
Camshaft systemSingle overhead camshaft(SOHC)
Bore X Stoke (mm)58 x 56.6
Cooling systemWater cooling
Fuel95 and above
Compression ratio12.5:1
Displacement(ml)149.5
Fuel supply methodIntelligent electrical fuel injection
Electrical fuel injection systemBOSCH
Ignition systemElectronic ignition
Idling speed (r/min)1700 ± 100
Maximum power (kW/rpm)13.2 / 8700
Maximum torque (N.m/rpm)15.5/6500
Transmission typeCVT Automatic Transmission
Economical consumption of fuel (L/km)2.1 /100
Suspension system
Frame systemAluminum alloy frame
Tire structureSemi-slick tires
Front rim sizeMT:2.75×14
Rear rim sizeMT:3.5×13
Front tire specification110/70-14
Rear tire specification130/70-13
Front brake specificationDisc brake
Rear brake specificationDisc brake
Headlamp/tail light/steering lampLED
Brake systemDual-Channel ABS System









Unstoppable
Witness a New Era
The 150cc engine features a four-valve design and a 12.5:1 compression ratio,
paired with an efficient liquid-cooling system. It delivers class-leading output of
13.2 kW and 15.5 N·m while maintaining low fuel consumption. A linerless pure
aluminum cylinder, lightweight forged piston, and DLC-coated piston rings ensure
excellent heat dissipation, strong power output, and superior fuel efficiency.
Piston cooling, dedicated lubrication, and dual oil filtration effectively minimize wear,
resulting in a more stable and durable engine.
100000 12.5:1
150cc
High compression ratio
1000 13.2
kW
Maximum power
1000 15.5
N·m
Maximum torsion
One-Piece Cast Aluminum Frame
The world's first high-strength, lightweight one-piece cast aluminum frame in the 150cc class, tipping the scales at no more than 8.5 kg. The total curb weight of just 108 kg is significantly lighter than comparable models in its class. This lightweight construction translates into outstanding handling — the nimble chassis delivers an intuitive, connected riding experience where power is always on tap. Even riders with a smaller build will find daily maneuvering effortless.
Lightweight Platform
The combination of efficient power and a lightweight platform
delivers exceptional performance, firmly establishing
the 150X as a leader in its class.
Spacious and Versatile Storage
Generous storage throughout the motorcycle accommodates a wide range of everyday needs.
Large-Capacity Under-Seat Storage

Large-Capacity Under-Seat Storage

Large-Capacity Under-Seat Storage,Fits two standard full-face helmets simultaneously.

左前置物箱

Left front compartment

The left front compartment fits a phone for charging.

右前置物箱

Right front compartment

The right front compartment fits a 550 ml bottle of drinking water.

Convenient Front Hook

Convenient Front Hook

Gives riders an additional option for carrying small items (recommended maximum load: 1 kg) for quick and easy access.

Confident Ergonomics, Enjoyable Riding
The carefully engineered riding triangle accommodates riders from 5'0"" to 6'1"", making it easy to find a comfortable riding position.
Optional sport footpegs are available for shorter riders, providing added confidence and effortless control.
11L Large-Capacity Fuel Tank
Combined with its efficient powertrain and lightweight chassis, the 150X delivers an impressive fuel range of up to 500 km on a full tank, eliminating the hassle of frequent fill-ups.
Purpose-Built Tires
Meticulously Tuned Front and Rear Suspension
Precisely Tuned Braking System
Delivers a linear feel and strong stopping power, with a 100–0 km/h braking distance that leads the class.
<%--
--%>
图片加载中...
Technology-Enabled, Seamlessly Connected
5-Inch TFT Full-Color HD Instrument Display
All key vehicle information at a glance. Choose from three UI themes. Supports smartphone connectivity for navigation projection, screen mirroring, and OTA remote updates.
A full suite of practical functions is available, including mobile phone Bluetooth connection, call display and answering, tire pressure monitoring,
automatic brightness adjustment, real-time vehicle data monitoring, and vehicle diagnostics.
3.0 Keyless Control System
The Generation 3.0 keyless control system supports CAN communication for real-time interaction with the ECU, instrument panel, and other components.
Equipped with 4G, GPS, and Bluetooth capabilities, the mini proximity key, energizing every ride before you even set off.
ZONTES SMART
ZONTES SMART offers multiple vehicle management functions, including remote vehicle control, vehicle data access, vehicle authorization for other users, ride tracking, and remote upgrades.
Breaking Boundaries, Lighting the Way Ahead
Lightning-bolt position lights
An aggressive, combat-ready front end paired with sharp lightning-bolt position lights, their edges cutting through the play of light and shadow. Every arrival carries a natural aura of speed and power.
Four-matrix projector LED headlight
" Independent light sources provide wide, even coverage of the road ahead, with clear night vision and a heightened sense of safety in corners and on challenging roads. Professional-grade lighting comes straight from the factory, with no aftermarket modification needed."
Three-in-one integrated taillight
" Clear, even position lights and bright turn signals and brake lights make the bike more conspicuous on the road. The inverted-V taillight echoes the V-shaped front end. Its sharp styling catches the eye at once and instantly lifts the bike's looks."
Multi-Layer Protection for Total Peace of Mind
Pre-Drilled Camera Mounting Points
Factory-installed mounting points at both the front and rear of the motorcycle
allow for straightforward dash cam installation.
Total Control at Your Fingertips
The new Bosch fuel injection system makes every ride safer and more reliable.
Monitors the operational status of the front and rear wheels in real time, providing greater safety for the rider.
